| Item | NSW1010-5T-IN | NSW1010-8T-IN | NSW1010-5GT-IN | NSW1010-8GT-IN |
| Service port | 5 x 10/100Mbps port (RJ45) | 8 x10/100Mbps port (RJ45) | 5 x 10/100/1000Mbps port (RJ45) | 8 x 10/100/1000Mbps port (RJ45) |
| Network media | 10Base-T: Cat3, 4, 5 or higher UTP/STP (≤100m) 100Base-TX: Cat5 or higher UTP/STP (≤100m) | 10Base-T: Cat3, 4, 5 or higher UTP/STP (≤100m) 100Base-TX: Cat5 or higher UTP/STP (≤100m) 1000Base-TX: Cat5e or higher UTP/STP (≤100m) |
| Standards | IEEE802.3 (Ethernet) IEEE802.3u (fast Ethernet) IEEE802.3x (flow control) | IEEE802.3 (Ethernet) IEEE802.3u (fast Ethernet) IEEE802.3ab (Gigabit Ethernet) IEEE802.3x (flow control) |
| Switching capacity | 1Gbps | 1.6Gbps | 10Gbps | 16Gbps |
| Packet forwarding rate | 0.744Mpps | 1.19Mpps | 7.44Mpps | 11.9Mpps |
| MAC | 2K |
| Jumbo frame | 15K |
| Transfer mode | Store-and-forward |
| Dimensions | Product: 92*51*21.5mm Packaging: 93*82*51mm | Product: 145*60*21.5mm Packaging: 146*88*50mm | Product: 92*51*21.5mm Packaging: 93*82*51mm | Product: 145*60*21.5mm Packaging: 146*88*50mm |
| Carton information | Carton dimensions: 435*280*395mm Carton quantity: 100PCS Carton weight: 14.2kg | Carton dimensions: 530*475*315mm Carton quantity: 100PCS Carton weight: 17.6kg | Carton dimensions: 435*280*395mm Carton quantity: 100PCS Carton weight: 14.2kg | Carton dimensions: 530*475*315mm Carton quantity: 100PCS Carton weight: 17.6kg |
| Weight | Product: 0.062kg Packaging: 0.132kg | Product: 0.111kg Packaging: 0.166kg | Product: 0.062kg Packaging: 0.132kg | Product: 0.111kg Packaging: 0.166kg |
| Operating voltage | Adapter input voltage: AC 100V to 240V Switch input voltage: 5V, 1A |
| Mount method | Desktop mount, wall mount |
| Fan | Fanless | Fanless | Fanless | Fanless |
| Operating temperature | 0°C to 40°C |
| Operating humidity | 10% to 90% RH, noncondensing |
| Storage temperature | -20°C to 70°C |
| Storage humidity | 5% to 90% RH, noncondensing |
| Indicator | Power: Steady on: Connected to the power Off: Disconnected to the power |
Port: Steady on: Connected to the port Blinking: Transmitting data Off: Disconnected to the port |
