| Model | UAC-T124-AF28LM | UAC-T124-AF40LM |
| Sensor |
| Pixel | 4MP |
| Size | 1/3" |
| Minimum illumination | 0.005 lux (F1.6, AGC ON) 0 lux (IR on) |
| Lens |
| Lens | 2.8mm | 4.0mm |
| Lens mount | M12 |
| Angle of view | H: 97.7° V: 54.9° D: 111.9° | H: 81.1° V: 41.0° D: 94.4° |
| Illuminator |
| Illuminator | Two IR illuminators |
| Illumination distance | 40m |
| Lifetime | ≥60,000 hours |
| Video |
| Resolution | 4MP: 2560(H) × 1440(V) 1080P: 1920(H)×1080(V) |
| Frame rate | TVI/AHD/CVI: 4MP@25fps (default), 4MP@30fps,1080P@25fps, 1080P@30fps CVBS: PAL, NTSC |
| Shutter time | PAL: 1/25s-1/50000s NTSC: 1/30s–1/50000s |
| Image |
| Exposure mode | Four modes: Global (default), BLC, HLC, DWDR |
| Day/Night | Three modes: Auto (default), Day, Night |
| Digital noise reduction | 2D |
| White balance | Two modes: Auto (default), Manual |
| WDR | DWDR |
| Smart IR | Support |
| Flip | Supports 180° horizontal flip, 180° vertical flip |
| Audio |
| Microphone | Built-in Mic |
| Camera audio | TVI: 4MP@25fps, 4MP@30fps,1080P@25fps, 1080P@30fps CVI: 4MP@25fps, 4MP@30fps |
| Interface |
| Power | 5.5mm power interface |
| Video output | BNC, supports TVI/AHD/CVI/CVBS |
| Operating environment |
| Temperature | -30°C to 60°C (-22°F to 140°F) |
| Humidity | ≤95% (RH, non-condensing) |
| Surge protection | 4kV |
| Ingress protection | IP67 |
| General |
| Power | DC 12V (±25%), with reverse polarity protection, Max 3.5W |
| Mount | Surface mount (default), optional backbox, wall mount bracket |
| Dimensions | Φ111mm*98mm (diameter*height) |
| Material | Metal+Plastic |
| Weight | 334g (0.74lb) |
| Certification | CE, FCC, UL |
