| Channel | Channel 1 (Panorama) | Channel 2 (Detail) |
| Camera |
| Sensor | 1/2.8" CMOS |
| Min. Illumination | Color: 0.002 lux (F1.6, AGC ON) 0 lux with IR | Color: 0.002 lux (F1.6, AGC ON) 0 lux with IR/Warm light |
| Day/Night | IR?cut filter with auto switch (ICR) |
| Shutter | Auto/Manual, 1 to 1/100000 s |
| WDR | 120 dB |
| S/N | >52 dB |
| Lens |
| Focal Length | 2.8 mm | 2.8 to 12 mm |
| Optical Zoom | N/A | 4X |
| Iris | F1.6 |
| Field of View (H) | 102.4° | 106.6° ~ 30.6° |
| Field of View (V) | 54.9° | 56.5° ~ 17.4° |
| Field of View (D) | 133.1° | 138.6° ~ 37.6° |
| DORI |
| DORI Distance (Detect) | 43.4 m (142.5 ft) | 43.4 m ~ 162.9 m (142.5 ft ~ 534.6 ft) |
| DORI Distance (Observe) | 17.4 m (57.0 ft) | 17.4 m ~ 65.2 m (57.0 ft ~ 213.8 ft) |
| DORI Distance (Recognize) | 8.7 m (28.5 ft) | 8.7 m ~ 32.6 m (28.5 ft ~ 106.9 ft) |
| DORI Distance (Identify) | 4.3 m (14.3 ft) | 4.3 m ~ 16.3 m (14.3 ft ~ 53.5 ft) |
| Illuminator |
| Wavelength | 850 nm |
| Light On/Off Control | Auto/Manual |
| Illumination Distance (IR) | 10 m (32.8 ft) | 50 m (164.0 ft) |
| Illumination Distance (Warm Light) | N/A | 10 m (32.8 ft) |
| Image |
| Defog | Digital Defog |
| White Balance | Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2 |
| Digital Noise Reduction | 2D/3D DNR |
| Smart IR | Support |
| Flip | Normal, Flip Vertical, Flip Horizontal, 180° |
| HLC | Support |
| BLC | Support |
| Intelligent |
| Linkage Function | Support. Triggered by fixed lens via smart intrusion prevention function to track target |
| Smart Intrusion Prevention | Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non?motor vehicle and vehicle) |
| Video |
| Frame Rate?Main Stream | 2MP (1920 x 1080) @25 fps (Default) 2MP (1920 x 1080), Max 25 fps 720P (1280 x 720), Max 25 fps |
| Frame Rate?Sub Stream | 720P (1280 x 720), Max 25 fps D1 (720 x 576), Max 25 fps 640 x 360, Max 25 fps 2CIF (704 x 288), Max 25 fps CIF (325 x 288), Max 25 fps |
| Privacy Mask | 24 areas, up to 4 areas per scene |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Video Bit Rate | 128 Kbps to 16 Mbps |
| U?code | Support (Main stream) |
| ROI | Support |
| Video Stream | Dual Streams |
| OSD | Up to 4 OSDs |
| Events |
| Basic Detection | Motion Detection, Audio Detection |
| General Function | Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| PTZ |
| Pan Range | N/A | 0° ~ 345° |
| Pan Speed | N/A | 1°/s ~ 40°/s |
| Tilt Range | 18° ± 5° | ?10° ~ 100° |
| Tilt Speed | N/A | 2°/s ~ 50°/s |
| Number of Presets | N/A | 256 |
| Preset Patrol | N/A | 16 patrols, up to 64 presets for each patrol |
| Patrol Stay Time | 1000 s to 1800 s |
| Home Position | N/A | Support |
| Audio |
| Audio Compression | G.711U, G.711A |
| Audio Bitrate | 128 Kbps |
| Two?way Audio | Support |
| Suppression | Support |
| Sampling Rate | 16KHz |
| Storage |
| Edge Storage | Micro SD, up to 512 GB |
| Network Storage | ANR, NAS (NFS) |
| Network |
| Protocols | SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile M), API, SDK |
| User/Host | Up to 32 users. 3 user levels: administrator, common user and operator |
| Security | TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF |
| Client | EZStation, UNV?Link, UNV?Link Pro |
| Web Browser | Plug?in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+ |
| Interface |
| Built?in Mic | Built?in two mics |
| Built?in Speaker | Support |
| Network | 1 × RJ45 10 M/100 M Base?TX Ethernet |
| Certification |
| EMC | CE?EMC (EN55032:2015; EN55024:2010+A1:2015; EN61000?3?2:2014; EN61000?3?3:2013) FCC (FCC CFR 47 part15 B, ANSI C63.4?2014) |
| Safety | CE LVD (EN 62368?1:2014+A11:2017; EN 62368?1:2014) UL (UL 62368?1, 2nd Ed., Issue Date: 2014?12?01) |
| Environment | CE?ROHS (2011/65/EU) |
| Protection | IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013) |
| General |
| Power | DC12V, PoE+ (IEEE 802.3at) |
| Power Consumption | MAX 16W |
| Power Interface | ?5.5 mm coaxial power plug |
| Dimensions | Wall Mount: 192 x 134 x 302 mm (7.6" x 5.3" x 11.9") (L x W x H) Ceiling Mount: 154 x 134 x 363 mm (6.1" x 5.3" x 14.3") (L x W x H) |
| Weight | 1.03 kg (2.27 lb) |
| Working Environment | ?20 ℃ to 60 ℃ (?4 ℉ to 140 ℉), Humidity: ≤ 95% RH (non?condensing) |
| Storage Environment | ?30 ℃ to 70 ℃ (?22 ℉ to 158 ℉), Humidity: ≤ 95% RH (non?condensing) |
| Surge Protection | 2 KV |
| Reset Button | Support |
| Web Client Language | 22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak |
