| Channel | Optical | Thermal |
| Camera |
| Sensor | 1/1.8" CMOS, resolution: 4MP (2688×1520) | VOx uncooled focal plane arrays, resolution: 640x512 |
| Min. Illumination | Colour : 0.0003lux(F1.2, AGC ON)B/W : 0.0001lux(F1.2, AGC ON)0 Lux with Laser | N/A |
| Response Waveband | N/A | 8 μm to 14 μm |
| Pixel Interval | 2 μm | 12 um |
| NETD | N/A | ≤ 40 mk@F1.0@25 ℃ |
| Day/Night mode | Auto/Manual | N/A |
| Focus Mode | Auto/Manual |
| Shutter | Auto/Manual, 1 to 1/100000 s |
| Lens |
| Focal Length | 6 ~ 336 mm | 75 mm |
| Optical Zoom | 56X | N/A |
| Iris | F1.2 to F4.6 |
| Field of View (H) | 57.9°~ 1.6° | 6.1° |
| Field of View (V) | 34.6°~ 0.9° | 4.8° |
| Field of View (D) | 71.2°~ 1.9° | 7.2° |
| DORI |
| DORI Distance (Detect) | 155.5m(510.1ft)~4829.4m(15844.5ft) | see page #5 of datasheet |
| DORI Distance (Observe) | 62.2m(204.0ft)~1931.8m(6337.8ft) | see page #5 of datasheet |
| DORI Distance (Recognize) | 31.1m(102.0ft)~965.9m(3168.9ft) | see page #5 of datasheet |
| DORI Distance (Identify) | 15.5m(51.0ft)~482.9m(1584.4ft) | see page #5 of datasheet |
| Illuminator |
| Illumination Distance (IR) | Up to 800m(2624.7ft) | N/A |
| Video |
| Video Resolution | Main Stream: 4MP (2688×1520): Max.60fps;Sub Stream: 2MP (1920×1080): Max.60fps;Third Stream: D1(720 x 576): Max.60fps; | 1080P(1920*1080), Max.30fps |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Video Bit Rate | 128 Kbps to 16 Mbps |
| U-code | Support |
| ROI | Support |
| Video Stream | Triple streams |
| OSD | Up to 8 OSDs |
| Privacy Mask | 24 areas, up to 8 areas per scene |
| Image |
| White Balance | Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2 | N/A |
| Digital Noise Reduction | 2D/3D DNR |
| Stabilization (Gyroscope) | Support |
| Defog | Digital defog, Optical defog |
| Anti-rain (wiper) | Support |
| Intelligent |
| Smart Function (bothmodules, optical and thermal) | Cross line detection, intrusion detection, enter/leave area detection, false alarm filtering,classification of human, animal, vehicle, non-motor vehicle, floating craft, flying machines |
| Smoke and Fire Detection | Support |
| Auto Tracking | Support tracking targets automatically, capturing detailed information at a distance |
| Events |
| Basic Detection | Motion Detection, Tampering Alarm, AudioDetection | N/A |
| General Function | Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, HTTP authentication, Alarm input, Alarm output |
| Audio |
| Audio Compression | G.711U, G.711A |
| Audio Bitrate | 128 Kbps |
| Two-way Audio | Support |
| Sampling Rate | 16KHZ |
| Storage |
| Edge Storage | MicroSD, up to 512 GB |
| Network Storage | ANR, NAS (NFS) |
| PTZ |
| Pan Range | 360° (endless) |
| Pan Speed | 0.02°/s ~ 140°/s |
| Tilt Range | -90° ~ 45° |
| Tilt Speed | 0.02° ~ 50°/s |
| Number of Presets | 1024 |
| Home Position | Support |
| 3D Location | Support |
| Network |
| Protocols | IPv6, L2TP, IPv4, ARP, TCP/IP, UDP, PPPoE, DHCP, RTP, RTSP, DNS, DDNS, NTP, FTP, UPnP,HTTP, SNMP, 802.1X, SIP, HTTPS, RTCP, RTMP, IGMP, ICMP, SMTP |
| Compatibility | ONVIF, GB/T 28181, API, SDK |
| Interface |
| Audio I/O | 1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2 V [p-p] |
| Alarm I/O | 7/2 |
| Serial Port | 1 × RS485 |
| Network | 1 × RJ45 10 M/100 M/1000 M Base-TX Ethernet + 1 × 100 M/1000 M SFP |
| Video Output | N/A | 1 BNC (For debugging) |
| General |
| Power | DC 48V±25%、DC 24V±15%、AC 24V±25% |
| Power Consumption | Max 135W |
| Power Interface | Wires with cold-pressed terminal |
| Dimensions | 366 x 283 x 509 mm (14.4" x 11.1" x 20.0")(L x W x H) |
| Weight | 17.98kg(39.64lb) |
| Working Environment | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing) |
| Storage Environment | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing) |
| Surge Protection | 6 KV |
| Reset Button | Support |
| RTC | Support |
| Certification |
| Protection | IP66 |
| Live View |
| OSD Font | Vector |
| OSD Character Number | 40 |
