| Model | IPC264EA-AHDZK-GE | IPC264EA?AHDX4K?I1 |
| Camera |
| Sensor | 1/1.8" CMOS |
| Min. Illumination | Colour:0.0003 lux (F1.2, AGC ON) B/W:0.0001 lux (F1.2, AGC ON) 0 lux with IR | Colour:0.0005 lux (F1.6, AGC ON) B/W:0.0003 lux (F1.6, AGC ON) 0 lux with IR |
| Day/Night | IR?cut filter with auto switch (ICR) |
| Shutter | Auto/Manual, 1 to 1/100000 s |
| WDR | 140 dB |
| S/N | >56 dB |
| Lens |
| Focal Length | 2.8 to 12 mm | 8 to 32 mm |
| Optical Zoom | 4X |
| Iris | F1.2 | F1.6 |
| Field of View (H) | 106.6°~ 50° | 42.6°~ 15.2° |
| Field of View (V) | 56.9°~ 28.6° | 23.5°~ 8.9° |
| Field of View (D) | 131.1°~ 63.1° | 52.4°~ 17.9° |
| Iris Type | P?iris |
| DORI |
| DORI Distance (Detect) | 68.0m(223.0ft)~166.2m(545.2ft) | 124.1m(407.3ft)~496.6m(1629.1ft) |
| DORI Distance (Observe) | 27.2m(89.2ft)~66.5m(218.1ft) | 49.7m(162.9ft)~198.6m(651.6ft) |
| DORI Distance (Recognize) | 13.6m(44.6ft)~33.2m(109.0ft) | 24.8m(81.5ft)~99.3m(325.8ft) |
| DORI Distance (Identify) | 6.8m(22.3ft)~16.6m(54.5ft) | 12.4m(40.7ft)~49.7m(162.9ft) |
| Illuminator |
| Illumination Distance (IR) | 100 m (328.1 ft) |
| IR On/Off Control | Auto/Manual |
| Wavelength | 850 nm |
| Video |
| Frame Rate?Main Stream | 4MP(2688*1520), Max 60fps |
| Frame Rate?Sub Stream | 2MP(1920*1080), Max 60fps; |
| Frame Rate?Third Stream | D1 (720*576), Max 60fps |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Frame Rate Recommendation | 2688*1520@60fps+1080P@60fps+D1@60fps |
| Video Bit Rate | 128 Kbps to 16 Mbps |
| ROI | Support |
| Privacy Mask | Up to 8 areas (8 blacks / 8 mosaics) |
| Video Stream | Triple Streams |
| OSD | Up to 10 OSDs |
| Image |
| White Balance | Auto&Outdoor&Fine Tune&Sodium Lamp&Locked&Auto2 |
| Digital Noise Reduction | 2D/3D DNR |
| Smart IR | Support |
| Defog | Digital Defog |
| Flip | Normal&Flip Vertical&Flip Horizontal&180°&90°Clockwise&90°Anti?clockwise |
| HLC | Support |
| BLC Auto | Support |
| Intelligent |
| Metadata Analyse | Support human body, human face, motor vehicle and non?motor vehicle image capture and attribute collection |
| Recognition | Face recognition: Max support 16 face libraries; Max supports 100000 faces in face library |
| People Counting | Support People Flow Counting and Crowd Density Monitoring |
| Exception Detection | Object Removed|Object Left Behind|Scene Change|Defocus Detection | Object Removed|Object Left Behind |
| Smart Intrusion Prevention | Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non?motor vehicle and vehicle) |
| Events |
| Basic Detection | Motion Detection|Tampering Alarm|Audio Detection|Object Removed|Object Left Behind|Scene Change|Defocus Detection | Motion Detection|Tampering Alarm|Audio Detection|Object Removed|Object Left Behind |
| General Function | Watermark&IP Address Filtering&Access Policy&ARP Protection&RTSP Authentication&User Authentication&HTTP authentication&Alarm input&Alarm output |
| Audio |
| Audio Compression | G.711U&G.711A |
| Audio Bitrate | 128 Kbps |
| Sampling Rate | 16KHZ |
| Storage |
| Edge Storage | Micro SD, up to 512 GB |
| Network Storage | ANR&NAS(NFS) |
| Network |
| Protocols | IGMP, RTP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS, SSH, TLS1.3 |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API, SDK |
| User/Host | Up to 32 users. 3 user levels: administrator, common user and operator |
| Security | Password protection&Strong password&HTTPS encryption&Export operation logs&Basic and digest authentication for RTSP&Digest authentication for HTTP&TLS 1.2&WSSE and digest authentication for ONVIF |
| Client | EZStation, UNV?Link, UNV?Link Pro |
| Web Browser | Plug?in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above&Plug?in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above |
| Interface |
| Audio I/O | 2 Input: impedance 1 kΩ, amplitude 2.5 V [p?p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p?p] |
| Alarm I/O | 3/2 |
| Serial Port | 1 channel RS485 interface |
| Built?in Mic | Support, built?in mic*2 |
| Built?in Speaker | Support |
| Network | 1 × RJ45 10 M/100 M/1000 M Base?TX Ethernet |
| Certification |
| EMC | CE?EMC (EN 55032: 2015+A1:2020,EN 61000?3?3: 2013+A1: 2019,EN IEC 61000?3?2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4?2014) |
| Safety | CE LVD (EN 62368?1:2014+A11:2017) UL (UL 62368?1, 2nd Ed., Issue Date: 2014?12?01) |
| Environment | CE?RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection | IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002) |
| General |
| Power | DC12V(±25%) , PoE+ (IEEE 802.3at) |
| Power Consumption | 16W | 19W |
| Power Interface | ?5.5 mm coaxial power plug |
| Dimensions | 406 x 126 x 130 mm (16.0” x 5.0” x 5.1”) (L x W x H) |
| Weight | 1.92kg(4.23lb) | 1.86kg(4.10lb) |
| Working Environment | ?40 ℃ to 60 ℃ (?40 ℉ to 140 ℉), Humidity: ≤ 95% RH (non?condensing) |
| Surge Protection | 6 KV |
| Reset Button | Support |
| Heater | Support |
